Graco E-Flo iQ - Prime Diagram; Depressurize Diagram

Integration
333587B 87
Prime Diagram
Depressurize Diagram
Prime
Automation Inputs (E-Flo iQ Outputs)
Automation Control Ready
Heart Beat (1Hz)
PLC Lockout Active
Pump Trying to Move
Prime Active
Automation Outputs (E-Flo iQ Inputs)
PLC Control Lockout
Prime Pressure Target (integer)
Prime Flow Target (integer)
P
r
i
me
I
nac
ti
ve
P
ump
R
eques
t
(
uses
th
e
i
nac
ti
ve pump
on tandem and active on single ram)
(Timeout)
Can all be
enabled at
once.
Depressurize
Automation Inputs (E-Flo iQ Outputs)
Automation Control Ready
Heart Beat (1Hz)
PLC Lockout Active
Depressurization Active
Automation Outputs (E-Flo iQ Inputs)
System Enable/Remote Start Request
PLC Control Lockout
Pl
a
t
en
D
epressur
i
ze
R
eques
t
or
Valve Depressurization Request
