Graco PrecisionSwirl - Integration Upgrade with Advanced Map

Models
10 3A2098S
Integration Upgrade with
Advanced Map
NOTE: See manual 3A4649 for more information.
Graco provides an upgraded software solution for PCF
systems that came with automation communication
gateway modules (CGM). The table below shows which
systems have the ability to upgrade their system with
the update kit (25C527). This kit includes new CGM
software, as well as a larger data map.
Benefits of Upgrading:
1. Direct access to important information such as flow-
rates and pressures of the system (all four fluid
plates).
2. Allows for a complete integration of a Graco PCF
system, meaning an ADM is no longer necessary.
3. Much easier set up and integrate.
4. Much more supporting documentation to identify
what is important.
NOTE: Only systems with Ethernet I/P and Device Net
are capable of upgrading to use the Advanced Map.
Table 1: Software Upgrade Tokens
Table 2: Fieldbus Setup Options
PCF
Model
User Interface
Description
Able to
Upgrade
Upgrade
Kit
PFxx0x Discrete (DGM) No N/A
PFxx1x Device Net
(CGM)
Yes 25C527
PFxx2x Ethernet I/P
(CGM)
Yes 25C527
PFxx3x ProfiBus (CGM) No N/A
PFxx4x ProfiNet (CGM) No N/A
PFxx6x Device Net
(CGM)
Already
has
upgrade
installed
Already
has
upgrade
installed
PFxx7x Ethernet I/P
(CGM)
Already
has
upgrade
installed
Already
has
upgrade
installed
Part Description Contents
  16K743
Includes PCF software for the
ADM, FCM, CGM, and DGM
System
Software
 * 16N601 PCF Gateway map token: Installs
the CGM map starting on
page 128.
Standard
Gateway
Map
16T061 PCF Gateway map token: Installs
the CGM map starting on page
128.
Basic
Gateway
Map (2
fluid plate),
No Swirl
 16K742 Historical PCF Gateway map
token: Only for users that used the
original PCF with a Gateway, have
purchased a new PCF, and do not
wish to change their Gateway
setup from the old Gateway map
to the new Gateway map.
Historical
Map
25C527 Advanced integration software kit.
Includes the latest PCF software
for the ADM, FCM, CGM, and
DGM (16K743). It also includes
the larger Map (17P799). Both of
these must be installed for the
CGM to run, and have advanced
integration features.
System
Software
and
Advanced
Map
Basic Gateway Map: 16T061
System Software: 16K743
Comm. Format: Data - SINT
Input Assembly Instance: 100
Input Instance Size: 10
Output Assembly Instance: 150
Output Instance Size: 6
Standard Gateway Map: 16N601
System Software: 16K743
Comm. Format: Data - SINT
Input Assembly Instance: 100
Input Instance Size: 26
Output Assembly Instance: 150
Output Instance Size: 42
Advanced Gateway Map: 17P799
System Software: 16K743 (newest version)
Comm. Format Data - SINT
Input Assembly Instance: 100
Input Instance Size 126
Output Assembly Instance: 150
Output Instance Size: 44
