Appendix C - Communications Gateway Module (CGM) Connection Details
3A2098S 131
CGM I/O Data Map
See Appendix D - I/O Signal Descriptions on page
146.
Automation Inputs (signals from PCF)
Byte
Input
Bit Description Zone
0
I00 Dispenser (Fluid Plate) Ready
Fluid
Plate 1
I01 Dispenser (Fluid Plate) No Alarm
I02 Dispense No Error
I03 Dispense in Process
I04 Dispense Volume OK
I05 ---
I06 Dispenser (Fluid Plate) Purge
Request
I07 Dispenser (Fluid Plate) Remote
Start / Purge In Process
1
I08 Pressure Units - Bit 0
Fluid
Plate 1
I09 Pressure Units - Bit 1
I10 Heartbeat
I11 ---
I12 ---
I13 ---
I14 ---
I15 ---
2
I16 ---
Fluid
Plate 1
I17 ---
I18 ---
I19 ---
I20 ---
I21 ---
I22 ---
I23 ---
3
I24 Error - 1
Fluid
Plate 1
I25 Error - 2
I26 Error - 4
I27 Error - 8
I28 Error - 16
I29 Error - 32
I30 Error - 64
I31 Error - 128
4
I32 Dispenser (Fluid Plate) Ready
Fluid
Plate 2
I33 Dispenser (Fluid Plate) No Alarm
I34 Dispense No Error
I35 Dispense in Process
I36 Dispense Volume OK
I37 ---
I38 Dispenser (Fluid Plate) Purge
Request
I39 Dispenser (Fluid Plate) Remote
Start / Purge In Process
5
I40 Pressure Units - Bit 0
Fluid
Plate 2
I41 Pressure Units - Bit 1
I42 Heartbeat
I43 ---
I44 ---
I45 ---
I46 ---
I47 ---
6
I48 ---
Fluid
Plate 2
I49 ---
I50 ---
I51 ---
I52 ---
I53 ---
I54 ---
I55 ---
7
I56 Error - 1
Fluid
Plate 2
I57 Error - 2
I58 Error - 4
I59 Error - 8
I60 Error - 16
I61 Error - 32
I62 Error - 64
I63 Error - 128
8
I64 Dispenser (Fluid Plate) Ready
Fluid
Plate 3
I65 Dispenser (Fluid Plate) No Alarm
I66 Dispense No Error
I67 Dispense in Process
I68 Dispense Volume OK
I69 ---
I70 Dispenser (Fluid Plate) Purge
Request
I71 Dispenser (Fluid Plate) Remote
Start / Purge In Process
9
I72 Pressure Units - Bit 0
Fluid
Plate 3
I73 Pressure Units - Bit 1
I74 Heartbeat
I75 ---
I76 ---
I77 ---
I78 ---
I79 ---
10
I80 ---
Fluid
Plate 3
I81 ---
I82 ---
I83 ---
I84 ---
I85 ---
I86 ---
I87 ---
Byte
Input
Bit Description Zone
