Models
4 3A2098S
Models
Check the identification (ID) plate for the 6-digit part number of the fluid metering system. Use the following matrix to
define the construction of the system, based on the six digits. For example, Part PF1110 represents a PCF fluid
metering system (PF), a two style system (1), a fluid plate with a cartridge regulator and no meter (1), a DeviceNet
™
user interface (1) with a 100-240 Vac power supply (0).
NOTE: To order replacement parts, see Parts section in this manual. The digits in the matrix do not correspond to the
Ref. Nos. in the Parts drawings and lists.
Discrete Gateway systems do not include automation interface cables. The following Graco accessories are avail-
able for wiring to the automation system. Installers should follow Appendix B - Discrete Gateway Module
(DGM) Connection Details, page 121, for custom wiring.
For single fluid plate systems only: 50 ft (15 m) cable with flying leads (123793)
All systems: Breakout board (123783) and 50 ft (15 m) cable (123792)
NOTE: 256 styles option is not available with Discrete Gateway systems.
These fluid metering systems have ETL certification.
NOTE: Fluid metering systems with heated mastic regulators are not ETL certified.
This product has been tested to the requirements of CAN/CSA-C22.2 No. 61010-1, second edition, including
Amendment 1, or a later version of the same standard incorporating the same level of testing requirements.
PF 1
1
1
0
First and
Second Digits
Third Digit
Fourth Digit
Fifth Digit
Sixth Digit
Style/Size
Fluid Plate
User Interface
Voltage
Description Regulator Meter Description Description
PF
(Precision
Continuous
Flow)
1 2 Styles 1 Cartridge None 0 Discrete 0 100 - 240 Vac
2
16 Styles 2 Mastic None 1
DeviceNet
™
1 24 Vdc
3 256 Styles 3 Cartridge High
Resolution
2
EtherNet/IP
™
2 100 - 240 Vac with
Integrated Swirl
4 Mastic High
Resolution
3
PROFIBUS
™
3 24 Vdc with
Integrated Swirl
5 Heated
Mastic
Heated
Standard Res-
olution
4
PROFINET
™
6 Heated Mas-
tic
None 5 Not Used.
6 DeviceNet
No ADM
7 Cartridge Ultra High
Resolution
7 EtherNet I/P
No ADM
8 Cartridge High
Resolution /GB
9 Mastic High
Resolution /GB
C Cartridge Coriolis
9902471
Certified to CAN/CSA C22.2 No. 61010-1
Conforms to
UL 61010-1
C
1
