Graco PrecisionSwirl - Related Manuals

Related Manuals
3A2098S 3
Appendix A - Advanced Display Module (ADM) 104
Display Overview . . . . . . . . . . . . . . . . . . . . . . . 104
Display Details . . . . . . . . . . . . . . . . . . . . . . . . . 104
Setup Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Run Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Appendix B - Discrete Gateway Module (DGM)
Connection Details . . . . . . . . . . . . . . . . . . . . 121
D-Sub Cable 123793 . . . . . . . . . . . . . . . . . . . . 121
D-Sub Cable 123792 and Breakout Board 123783
122
DGM Digital Input . . . . . . . . . . . . . . . . . . . . . . 125
DGM Digital Outputs . . . . . . . . . . . . . . . . . . . . 126
DGM Analog Inputs . . . . . . . . . . . . . . . . . . . . . 127
DGM Analog Outputs . . . . . . . . . . . . . . . . . . . 127
Appendix C - Communications Gateway Module
(CGM) Connection Details . . . . . . . . . . . . . . 128
Install Fieldbus Connections . . . . . . . . . . . . . . 128
CGM I/O Data Map . . . . . . . . . . . . . . . . . . . . . 131
Appendix D - I/O Signal Descriptions . . . . . . . . 146
Automation Inputs . . . . . . . . . . . . . . . . . . . . . . 146
Automation Outputs . . . . . . . . . . . . . . . . . . . . . 147
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Swirl Dispenser Technical Data . . . . . . . . . . . 148
Fluid Plate Assembly Technical Data . . . . . . . 149
Control Center Assembly Technical Data . . . . 149
Graco Standard Warranty . . . . . . . . . . . . . . . . . . 150
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . 150
Related Manuals
The following is a list of component manuals written in
English. These manuals and any available translations
can be found at www.graco.com.
NOTE: In the Advanced screens on your system, if the
Advanced Display software part number shown is
16F528 or 15V769 then this manual does not apply to
your system; refer to manual 313377 for your system.
Otherwise, the part number shown should be 16K405
and you should use this manual.
Manual Description
313377
Original PCF Instructions - Parts
(see the note below)
309403 PrecisionSwirl Orbital Dispenser
307517
Mastic Fluid Regulators Instruc-
tions-Parts
308647
Fluid Pressure Regulators Instruc-
tions-Parts
309834
Helical Gear Fluid Flow Meters Instruc-
tions-Parts
3A4649 Integrated PCF Instructions
3A5295 Coriolis Flow Meter Instructions - Parts
ADM Software Part No. 16F528 or 15V769
(see manual 313377)
ADM Software Part No. 16K405
(use this manual)


