Models
8 3A2098S
Expansion Swirl Enclosure Assemblies
The following enclosures are ETL approved. Assemblies PFxxx2, and PFxxx3 are setup for one PrecisionSwirl Orbital
Dispenser. If you wish to have additional swirl dispensers, order one expansion PrecisionSwirl assembly below for each.
Systems with a DGM as the automation gateway can have up to two swirl dispensers total. Systems with a CGM as the
automation gateway can have up to four swirl dispensers total.
PrecisionSwirl Orbital Dispenser Assemblies
See manual 309403.
PrecisionSwirl Orbital Dispenser Cable
Assemblies
Part Description
16M350 100 - 240 Vac
16M351 24 Vdc
Version Part, Series Coupler Offset Typical Application
Maximum
Working
Pressure
Standard 243402, B 0.012 in. for narrow bead
widths
Hem flange and after hem
3500 psi
(24.1 MPa,
241 bar)
Standard 243403, B 0.028 in. for wide bead
widths
Seam sealing
Compact 289262, A 0.012 in. for narrow bead
widths
Hem flange and after hem
Compact 289261, A 0.018 in. for medium bead
widths
Seam sealing
Part Description
233125 6 ft (1.8 m) motor extension cable assembly
233124 9 ft (2.7 m) motor extension cable assembly
233123 15 ft (4.6 m) motor extension cable assembly
617870 55 ft (16.8 m) motor extension cable assembly
