Graco PrecisionSwirl - Page 132

Appendix C - Communications Gateway Module (CGM) Connection Details
132 3A2098S
11
I88 Error - 1
Fluid
Plate 3
I89 Error - 2
I90 Error - 4
I91 Error - 8
I92 Error - 16
I93 Error - 32
I94 Error - 64
I95 Error - 128
12
I96 Dispenser (Fluid Plate) Ready
Fluid
Plate 4
I97 Dispenser (Fluid Plate) No Alarm
I98 Dispense No Error
I99 Dispense in Process
I100 Dispense Volume OK
I101 ---
I102 Dispenser (Fluid Plate) Purge
Request
I103 Dispenser (Fluid Plate) Remote
Start / Purge In Process
13
I104 Pressure Units - Bit 0
Fluid
Plate 4
I105 Pressure Units - Bit 1
I106 Heartbeat
I107 ---
I108 ---
I109 ---
I110 ---
I111 ---
14
I112 ---
Fluid
Plate 4
I113 ---
I114 ---
I115 ---
I116 ---
I117 ---
I118 ---
I119 ---
15
I120 Error - 1
Fluid
Plate 4
I121 Error - 2
I122 Error - 4
I123 Error - 8
I124 Error - 16
I125 Error - 32
I126 Error - 64
I127 Error - 128
16
I128 Command Interface - Value - Bit 0
See CGM Command Interface on
page 138 for command interface
details.
All Fluid
Plates/Swi
rls
I129 Command Interface - Value - Bit 1
I130 Command Interface - Value - Bit 2
I131 Command Interface - Value - Bit 3
I132 Command Interface - Value - Bit 4
I133 Command Interface - Value - Bit 5
I134 Command Interface - Value - Bit 6
I135 Command Interface - Value - Bit 7
Byte
Input
Bit Description Zone
17
I136 Command Interface - Value - Bit 8
All Fluid
Plates/Swi
rls
I137 Command Interface - Value - Bit 9
I138 Command Interface - Value - Bit 10
I139 Command Interface - Value - Bit 11
I140 Command Interface - Value - Bit 12
I141 Command Interface - Value - Bit 13
I142 Command Interface - Value - Bit 14
I143 Command Interface - Value - Bit 15
18
I144 Command Interface - Value - Bit 16
All Fluid
Plates/Swi
rls
I145 Command Interface - Value - Bit 17
I146 Command Interface - Value - Bit 18
I147 Command Interface - Value - Bit 19
I148 Command Interface - Value - Bit 20
I149 Command Interface - Value - Bit 21
I150 Command Interface - Value - Bit 22
I151 Command Interface - Value - Bit 23
19
I152 Command Interface - Value - Bit 24
All Fluid
Plates/Swi
rls
I153 Command Interface - Value - Bit 25
I154 Command Interface - Value - Bit 26
I155 Command Interface - Value - Bit 27
I156 Command Interface - Value - Bit 28
I157 Command Interface - Value - Bit 29
I158 Command Interface - Value - Bit 30
I159 Command Interface - Value - Bit 31
20
I160 Command Interface Status - Com-
mand Active
All Fluid
Plates/Swi
rls
I161 Command Interface Status - Com-
mand Success
I162 Command Interface Status - Com-
mand Failure
I163 Command Interface Status - Value
Coerced
I164 ---
I165 ---
I166 ---
I167 ---
21-
25
I168-
I207
--- ---
Byte
Input
Bit Description Zone
