Graco PrecisionSwirl - Automation Outputs (signals to PCF)

Appendix C - Communications Gateway Module (CGM) Connection Details
3A2098S 133
Automation Outputs (signals to PCF)
Byte
Output
Bit Description Zone
0
O00 Style Strobe
Fluid
Plate 1
O01 Dispense Complete
O02 Dispense Valve 1 On
O03 Dispense Valve 2 On
O04 Dispense Valve 3 On
O05 Dispense Valve 4 On
O06 Error Reset / Cancel Job
O07 Remote Start / Purge
1
O08 Swirl Enable
Swirl 1
O09 ---
O10 ---
O11 ---
O12 ---
O13 ---
O14 ---
O15 ---
2
O16 Style - 1
Fluid
Plate 1
O17 Style - 2
O18 Style - 4
O19 Style - 8
O20 Style - 16
O21 Style - 32
O22 Style - 64
O23 Style - 128
3
O24 Dispense Valve 1 Precharge On
Fluid
Plate 1
O25 Dispense Valve 2 Precharge On
O26 Dispense Valve 3 Precharge On
O27 Dispense Valve 4 Precharge On
O28 ---
O29 ---
O30 ---
O31 ---
4
O32 Command Value - 1
Fluid
Plate 1
O33 Command Value - 2
O34 Command Value - 4
O35 Command Value - 8
O36 Command Value - 16
O37 Command Value - 32
O38 Command Value - 64
O39 Command Value - 128
5
O40 Command Value - 256
Fluid
Plate 1
O41 Command Value - 512
O42 Command Value - 1024
O43 Command Value - 2048
O44 ---
O45 ---
O46 ---
O47 ---
6
O48 Swirl Command Value - 1
Swirl 1
O49 Swirl Command Value - 2
O50 Swirl Command Value - 4
O51 Swirl Command Value - 8
O52 Swirl Command Value - 16
O53 Swirl Command Value - 32
O54 Swirl Command Value - 64
O55 Swirl Command Value - 128
7
O56 Swirl Command Value - 256
Swirl 1
O57 Swirl Command Value - 512
O58 Swirl Command Value - 1024
O59 Swirl Command Value - 2048
O60 ---
O61 ---
O62 ---
O63 ---
8
O64 Style Strobe
Fluid
Plate 2
O65 Dispense Complete
O66 Dispense Valve 1 On
O67 Dispense Valve 2 On
O68 Dispense Valve 3 On
O69 Dispense Valve 4 On
O70 Error Reset / Cancel Job
O71 Remote Start / Purge
9
O72 Swirl Enable
Swirl 2
O73 ---
O74 ---
O75 ---
O76 ---
O77 ---
O78 ---
O79 ---
10
O80 Style - 1
Fluid
Plate 2
O81 Style - 2
O82 Style - 4
O83 Style - 8
O84 Style - 16
O85 Style - 32
O86 Style - 64
O87 Style - 128
11
O88 Dispense Valve 1 Precharge On
Fluid
Plate 2
O89 Dispense Valve 2 Precharge On
O90 Dispense Valve 3 Precharge On
O91 Dispense Valve 4 Precharge On
O92 ---
O93 ---
O94 ---
O95 ---
Byte
Output
Bit Description Zone
