Appendix C - Communications Gateway Module (CGM) Connection Details
134 3A2098S
12
O96 Command Value - 1
Fluid
Plate 2
O97 Command Value - 2
O98 Command Value - 4
O99 Command Value - 8
O100 Command Value - 16
O101 Command Value - 32
O102 Command Value - 64
O103 Command Value - 128
13
O104 Command Value - 256
Fluid
Plate 2
O105 Command Value - 512
O106 Command Value - 1024
O107 Command Value - 2048
O108 ---
O109 ---
O110 ---
O111 ---
14
O112 Swirl Command Value - 1
Swirl 2
O113 Swirl Command Value - 2
O114 Swirl Command Value - 4
O115 Swirl Command Value - 8
O116 Swirl Command Value - 16
O117 Swirl Command Value - 32
O118 Swirl Command Value - 64
O119 Swirl Command Value - 128
15
O120 Swirl Command Value - 256
Swirl 2
O121 Swirl Command Value - 512
O122 Swirl Command Value - 1024
O123 Swirl Command Value - 2048
O124 ---
O125 ---
O126 ---
O127 ---
16
O128 Style Strobe
Fluid
Plate 3
O129 Dispense Complete
O130 Dispense Valve 1 On
O131 Dispense Valve 2 On
O132 Dispense Valve 3 On
O133 Dispense Valve 4 On
O134 Error Reset / Cancel Job
O135 Remote Start / Purge
17
O136 Swirl Enable
Swirl 3
O137 ---
O138 ---
O139 ---
O140 ---
O141 ---
O142 ---
O143 ---
18
O144 Style - 1
Fluid
Plate 3
O145 Style - 2
O146 Style - 4
O147 Style - 8
O148 Style - 16
O149 Style - 32
O150 Style - 64
O151 Style - 128
Byte
Output
Bit Description Zone
19
O152 Dispense Valve 1 Precharge On
Fluid
Plate 3
O153 Dispense Valve 2 Precharge On
O154 Dispense Valve 3 Precharge On
O155 Dispense Valve 4 Precharge On
O156 ---
O157 ---
O158 ---
O159 ---
20
O160 Command Value - 1
Fluid
Plate 3
O161 Command Value - 2
O162 Command Value - 4
O163 Command Value - 8
O164 Command Value - 16
O165 Command Value - 32
O166 Command Value - 64
O167 Command Value - 128
21
O168 Command Value - 256
Fluid
Plate 3
O169 Command Value - 512
O170 Command Value - 1024
O171 Command Value - 2048
O172 ---
O173 ---
O174 ---
O175 ---
22
O176 Swirl Command Value - 1
Swirl 3
O177 Swirl Command Value - 2
O178 Swirl Command Value - 4
O179 Swirl Command Value - 8
O180 Swirl Command Value - 16
O181 Swirl Command Value - 32
O182 Swirl Command Value - 64
O183 Swirl Command Value - 128
23
O184 Swirl Command Value - 256
Swirl 3
O185 Swirl Command Value - 512
O186 Swirl Command Value - 1024
O187 Swirl Command Value - 2048
O188 ---
O189 ---
O190 ---
O191 ---
24
O192 Style Strobe
Fluid
Plate 4
O193 Dispense Complete
O194 Dispense Valve 1 On
O195 Dispense Valve 2 On
O196 Dispense Valve 3 On
O197 Dispense Valve 4 On
O198 Error Reset / Cancel Job
O199 Remote Start / Purge
25
O200 Swirl Enable
Swirl 4
O201 ---
O202 ---
O203 ---
O204 ---
O205 ---
O206 ---
O207 ---
Byte
Output
Bit Description Zone
