Graco PrecisionSwirl - Page 135

Appendix C - Communications Gateway Module (CGM) Connection Details
3A2098S 135
26
O208 Style - 1
Fluid
Plate 4
O209 Style - 2
O210 Style - 4
O211 Style - 8
O212 Style - 16
O213 Style - 32
O214 Style - 64
O215 Style - 128
27
O216 Dispense Valve 1 Precharge On
Fluid
Plate 4
O217 Dispense Valve 2 Precharge On
O218 Dispense Valve 3 Precharge On
O219 Dispense Valve 4 Precharge On
O220 ---
O221 ---
O222 ---
O223 ---
28
O224 Command Value - 1
Fluid
Plate 4
O225 Command Value - 2
O226 Command Value - 4
O227 Command Value - 8
O228 Command Value - 16
O229 Command Value - 32
O230 Command Value - 64
O231 Command Value - 128
29
O232 Command Value - 256
Fluid
Plate 4
O233 Command Value - 512
O234 Command Value - 1024
O235 Command Value - 2048
O236 ---
O237 ---
O238 ---
O239 ---
30
O240 Swirl Command Value - 1
Swirl 4
O241 Swirl Command Value - 2
O242 Swirl Command Value - 4
O243 Swirl Command Value - 8
O244 Swirl Command Value - 16
O245 Swirl Command Value - 32
O246 Swirl Command Value - 64
O247 Swirl Command Value - 128
31
O248 Swirl Command Value - 256
Swirl 4
O249 Swirl Command Value - 512
O250 Swirl Command Value - 1024
O251 Swirl Command Value - 2048
O252 ---
O253 ---
O254 ---
O255 ---
Byte
Output
Bit Description Zone
32
O256
Command Interface - Command -
Bit 0
See CGM Command Interface on
page 138 for command interface
details.
All Fluid
Plates/S
wirls
O257
Command Interface - Command -
Bit 1
O258
Command Interface - Command -
Bit 2
O259
Command Interface - Command -
Bit 3
O260
Command Interface - Command -
Bit 4
O261
Command Interface - Command -
Bit 5
O262
Command Interface - Command -
Bit 6
O263
Command Interface - Command -
Bit 7
33
O264
Command Interface - Command -
Bit 8
All Fluid
Plates/S
wirls
O265
Command Interface - Command -
Bit 9
O266
Command Interface - Command -
Bit 10
O267
Command Interface - Command -
Bit 11
O268
Command Interface - Command -
Bit 12
O269
Command Interface - Command -
Bit 13
O270
Command Interface - Command -
Bit 14
O271
Command Interface - Command -
Bit 15
34
O272
Command Interface - Command -
Bit 16
All Fluid
Plates/S
wirls
O273
Command Interface - Command -
Bit 17
O274
Command Interface - Command -
Bit 18
O275
Command Interface - Command -
Bit 19
O276 ---
O277 ---
O278 ---
O279 ---
35
O280-
O287
--- ---
Byte
Output
Bit Description Zone
