Appendix C - Communications Gateway Module (CGM) Connection Details
136 3A2098S
36
O288
Command Interface - Value - Bit 0
See CGM Command Interface on
page 138 for command interface
details.
All Fluid
Plates/S
wirls
O289 Command Interface - Value - Bit 1
O290 Command Interface - Value - Bit 2
O291 Command Interface - Value - Bit 3
O292 Command Interface - Value - Bit 4
O293 Command Interface - Value - Bit 5
O294 Command Interface - Value - Bit 6
O295 Command Interface - Value - Bit 7
37
O296 Command Interface - Value - Bit 8
All Fluid
Plates/S
wirls
O297 Command Interface - Value - Bit 9
O298 Command Interface - Value - Bit 10
O299 Command Interface - Value - Bit 11
O300 Command Interface - Value - Bit 12
O301 Command Interface - Value - Bit 13
O302 Command Interface - Value - Bit 14
O303 Command Interface - Value - Bit 15
38
O304 Command Interface - Value - Bit 16
All Fluid
Plates/S
wirls
O305 Command Interface - Value - Bit 17
O306 Command Interface - Value - Bit 18
O307 Command Interface - Value - Bit 19
O308 Command Interface - Value - Bit 20
O309 Command Interface - Value - Bit 21
O310 Command Interface - Value - Bit 22
O311 Command Interface - Value - Bit 23
39
O312 Command Interface - Value - Bit 24
All Fluid
Plates/S
wirls
O313 Command Interface - Value - Bit 25
O314 Command Interface - Value - Bit 26
O315 Command Interface - Value - Bit 27
O316 Command Interface - Value - Bit 28
O317 Command Interface - Value - Bit 29
O318 Command Interface - Value - Bit 30
O319 Command Interface - Value - Bit 31
40
O320
Command Interface - Control Bits -
Read
All Fluid
Plates/S
wirls
O321
Command Interface - Control Bits -
Write
O322 ---
O323 ---
O324 ---
O325 ---
O326 ---
O327 ---
41
O328-
O335
--- ---
Byte
Output
Bit Description Zone
