Appendix C - Communications Gateway Module (CGM) Connection Details
144 3A2098S
Swirl Commands
Output
Bits
264-275 Description Gateway Units
Read or
Write
0x004 Software Part
Number
STR_3_0 Read Only
0x005 Software Part
Number
STR_7_4 Read Only
0x006 Software Part
Number
STR_11_8 Read Only
0x007 Software Part
Number
STR_15_12 Read Only
0x00B Software Version Version Read Only
0x400 Swirl Speed
Source
Speed Source
Enumeration
Read /
Write
0x401 Swirl Fixed Speed ##### (RPM) Read /
Write
0x403 Swirl Speed Scal-
ing
### (percent) Read /
Write
0x404 Swirl Maintenance
Time Advisory
Limit
###### (hours) Read /
Write
0x3FF Swirl - Actual Run
Time
###### (hours) Read /
Write
0x2FC Swirl Status Bits 1 Swirl Status Bit-
field 1
Read Only
0x4FE Swirl Actual Speed ##### (RPM) Read Only
0x500 Swirl Control Swirl Control
Enumeration
Read /
Write
0x501 Swirl Requested
Speed
uint12 Read /
Write
