Operation
3A2098S 59
Control Charts (continued)
Automation Inputs (PCF Outputs)
Dispense In Process
Automation Outputs (PCF Gateway Inputs)
Dispense Valve X On
PCF State
Regulator Active (Precharge = 0)
Trigger Using Command Cable and Gateway (Combined)
Dispense Valve Y On
Dispense Valve X On
Dispense Valve Y On
Command Cable
Dispense Trigger
Trigger Using Command Cable
* Dispense Valve X Open determined by Enable Valves check
boxes on Fluid Plate x, screen 1(Control Settings).
Automation Inputs (PCF Outputs)
Dispense In Process
Command Cable
Dispense Trigger
PCF State
Regulator Active (Precharge = 0)
Dispense Valve X Open*
Automation Inputs (PCF Outputs)
Dispense In Process
Automation Outputs (PCF Gateway Inputs)
Dispense Valve 1 On
PCF State
Regulator Active (Precharge = 0)
Trigger Using Gateway
Dispense Valve 2 On
Dispense Valve 3 On
Dispense Valve 4 On
Dispense Valve 1 On
Dispense Valve 2 On
Dispense Valve 3 On
Dispense Valve 4 On
