Graco QUANTM i30 - LED Indicator; LED Indicator Overview and Troubleshooting

LED Indicator
3A8572B 25
LED Indicator
LED Indicator Overview
LED Indicator Equipment Status Notes
Red, solid Powered on, speed set at 0 (zero),
system not operating.
Be aware that the equipment is energized.
To initiate equipment operation, follow Start the
Equipment, page 22.
Red, flashing Motor fault, motor error. See Troubleshoot LED Indicator Event Errors,
page 26.
Yellow, solid Calibrating. Performing startup
sequence.
No action. Allow equipment to finish startup
sequence.
Open the fluid drain valve (G) or fluid shutoff
valve (H) to allow the equipment to cycle until
the startup sequence is finished.
Yellow, flashing Leak sensor alert. See “Leak sensor alert” Troubleshoot LED
Indicator Event Errors, page 27.
Green, solid Startup sequence complete. To initiate equipment operation, follow Start the
Equipment, page 22.
Normal operation. No action.
Green, flashing Normal operation, stalled against
pressure.
Be aware that the equipment is energized.
Special-case action. See Troubleshoot LED
Indicator Event Errors, page 26.
No light (off) System not powered. See Troubleshoot LED Indicator Event Errors,
page 26.
