Technical Specifications for i80 (QTD) Models
QUANTM i80 (QTD) Pumps
US Metric
Maximum fluid working pressure 100 psi 6.89 bar, 0.69 MPa
Maximum free-flow delivery 80 gpm 227 lpm
Maximum size pumpable solids 0.19 in. 4.8 mm
Environmental temperature range -4° to 104°F –20° to 40°C
Maximum operating altitude 9842 ft 3000 m
Electrical ratings
Rated Voltage Phase Hertz Current
i80 (QTD) models, FC1 motor 200–240 V 3 50/60 Hz 7.5 A
i80 (QTD) models, FC2 motor 200–240 V 1 50/60 Hz 15 A
i80 (QTD) models, FC3 motor 200–240 V 3 50/60 Hz 7.5 A
i80 (QTD) models, FC4 motor 200–240 V 1 50/60 Hz 15 A
Materials of construction
See Configuration Matrix, starting on page 7, for materials of construction for your equipment model.
Fluid inlet/outlet sizes
Models with wetted section materials coded:
AL, SS 1.5 in. npt(f) or 1.5 in. bspt
CP, PP, PV 1.5 in. ANSI/DIN Raised Face Flange
Maximum suction lift*
Wet 18.0 ft 5.48 m
Dry 19.3 ft 5.9 m
Noise (dBa)
Maximum sound pressure 72 dBa at full power and full flow
Sound pressure measured 1.6 feet (0.5 meter) from equipment.
Sound power measured per ISO-9614-2.
Weight
Models with wetted section materials coded:
AL 71 lb 32.2 kg
SS 112 lb 50.8 kg
CP, PP 75 lb 34.0 kg
PV 85 lb 38.5 kg
Notes
* May vary based on pump materials, suction condition, discharge head, pressure, and fluid type.
All trademarks or registered trademarks are the property of their respective owners.
