Dimensions
3A8572B 45
i30 (QTC) Model Dimensions
Ref.
Wetted Section Material
AL SS, HT CP, PP, PV
in. cm in. cm in. cm
A 14.70 37.34
13.90 35.31 15.20 38.61
B 7.35 18.67
6.58 16.71 8.00 20.32
C 13.25 33.66
13.25 33.66 13.25 33.66
D 4.57 11.61
4.57 11.61 4.57 11.61
E 15.94 40.49
13.70 34.80 17.80 45.21
F 14.44 36.68
12.90 32.77 15.70 39.88
G 1.76 4.47
1.10 2.79 2.50 6.35
H 3.70 9.40
2.20 5.59 4.69 11.91
J 5.00 12.70
5.00 12.70 5.00 12.70
K 5.50 13.97
5.50 13.97 10.42 26.47
