Dimensions
3A8572B 47
i80 (QTD) Model Dimensions
Ref.
Wetted Section Material
AL SS PP, PV
in. cm in. cm in. cm
A
15.07 38.28 16.10 40.89 17.60 44.70
C
13.81 35.08 13.85 35.18 13.87 35.23
D
5.17 13.13 5.21 13.23 5.23 13.28
E
19.60 49.78 18.97 48.18 22.00 55.88
F
18.30 46.48 17.75 45.09 19.30 49.02
G
1.50 3.81 1.44 3.66 3.00 7.62
H
4.55 11.56 4.55 11.56 5.85 14.86
J
6.00 15.24 6.00 15.24 6.00 15.24
K
6.00 15.24 6.00 15.24 6.00 15.24
