Graco QUANTM i30 - Page 49

Dimensions
3A8572B 49
i120 (QTE) Model Dimensions
Ref.
Wetted Section Material
AL CI, SS CP, PP, PV
in. cm in. cm in. cm
A
17.50 44.45 18.13 46.05 19.70 50.04
B
9.00 22.86 9.40 23.88 11.00 27.94
C
14.89 37.82 14.89 37.82 14.89 37.82
D
6.25 15.88 6.25 15.88 6.25 15.88
E
23.60 59.94 26.34 66.90 25.70 65.28
F
21.90 55.63 24.79 62.97 22.70 57.66
G
2.00 5.08 2.50 6.35 3.50 8.89
H
6.72 17.07 9.01 22.89 7.53 19.13
J
6.00 15.24 6.00 15.24 6.00 15.24
K
6.00 15.24 6.50 16.51 6.00 15.24
