Configuration Matrix
8 3A8572B
Seat Material Check Material Diaphragm Material Manifold Seal Material
AC Acetal AC Acetal, ball BN Buna-N -- None
AL Aluminum BN Buna-N, ball CO Polychloroprene
Overmold
PT PTFE
BN* Buna-N CR Polychloroprene,
standard, ball
FK Fluoroelastomer
FK* Fluoroelastomer CW Polychloroprene,
weighted, ball
GE Geolast
GE Geolast FK Fluoroelastomer,
ball
PO PTFE/EPDM Overmold
PP Polypropylene GE Geolast, ball PS PTFE/Santoprene,
two-piece
PV PVDF PT PTFE, ball SP Santoprene
SA 17-4PH Stainless Steel
with PTFE seals
SD 440C Stainless
Steel, ball
TP TPE
SP Santoprene SP Santoprene, ball
SS 316 Stainless Steel SS 316 Stainless
Steel, ball
TP* TPE TP TPE, ball
* Models with BN, FK, or TP seats do not use manifold seals.
Connection Options
A1 Aluminum, standard ports, NPT 00 Standard
A2 Aluminum, standard ports, BSP
C1 Conductive Polypropylene, center flange
C2 Conductive Polypropylene, end flange
F1 PVDF, center flange
F2 PVDF, end flange
I2 Iron, standard ports, BSP
P1 Polypropylene, center flange
P2 Polypropylene, end flange
S1 Stainless Steel, standard ports, NPT
S2 Stainless Steel, standard ports, BSP
S51 Stainless Steel, center flange, horizontal outlet
