Graco Reactor 2 H-XP3 Repair Parts

Parts
Quantity Quantity
Quantity
Ref. Ref.
Ref.
Part Part
Part
Description Description
Description
24U320 24U320
24U320
25N920 25N920
25N920
601160327
FITTING,unionadapter,90°
22
602118459
FITTING,union,swivel,3/4in.
22
603‡247503
MANIFOLD,strainer,inlet
22
60424U852
THERMOMETER,dial
22
60524U853
GAUGE,press,uid
22
606†
---
FILTER,replacement
22
607†‡128061PACKING,o-ring22
608‡16V879
CAP,lter
22
609‡555808
PLUG,1/4mpw/hexhd
22
610
15D757
HOUSING,thermometer,VisconHP
22
613109077
VALVE,ball3/4npt
1
2
614C20487
FITTING,nipple,hex
22
61524U851
TRANSDUCER,pressure,temperature(includesfoam)
2
616158586
FITTING,bushing
2
617158383
FITTING,unionadapter
2
618624545
FITTING,tee3/4mrunx1/4f
2
*
Optional 80 mesh lter 255082 (2 pack)
†
Included in 24V020 Inlet Filter and Seal Kit, 20 mesh (2 pack).
‡
Included in 247503 Manifold Repair Kit.
334946J
103
