Graco Reactor 2 H-XP3 Repair Parts

PressureReliefProcedure
Pressure Pressure
Pressure
Relief Relief
Relief
Procedure Procedure
Procedure
FollowthePressureReliefProcedure
wheneveryouseethissymbol.
Thisequipmentstayspressurizeduntil
pressureismanuallyrelieved.Tohelpprevent
seriousinjuryfrompressurizeduid,such
asskininjection,splashinguidandmoving
parts,followthePressureReliefProcedure
whenyoustopsprayingandbeforecleaning,
checking,orservicingequipment.
The Fusion AP gun is shown.
1.Presstostopthepumps.
2.Turnoffallheatzones.
3.Relievepressureingunandperformgun
shutdownprocedure.Seegunmanual.
4.ClosegunuidinletvalvesAandB.
5.Shutofffeedpumpsandagitator,ifused.
6.Routeuidtowastecontainersorsupply
tanks.TurnPRESSURERELIEF/SPRAYvalves
(SA,SB)toPRESSURERELIEF/CIRCULATION
.Ensuregaugesdropto0.
7.Engagegunpistonsafetylock.
8.Disconnectgunairlineandremovegunuid
manifold.
334946J
49
