Propersystemsetup,startup,andshutdown
proceduresarecriticaltoelectricalequipment
reliability.Thefollowingproceduresensure
steadyvoltage.Failuretofollowthese
procedureswillcausevoltageuctuationsthat
candamageelectricalequipmentandvoidthe
warranty.
1.Presstostopthepumps.
2.Turnoffallheatzones.
3.Relievepressure.See
PressureReliefProcedure,page49.
4.PresstoparktheComponentAand
ComponentBpumps.Theparkoperation
iscompletewhengreendotgoesout.
Verifytheparkoperationiscompletebefore
movingtonextstep.
5.Presstodeactivatethesystem.
6.Turnofftheaircompressor,airdryer,and
breathingair.
7.TurnthemainpowerswitchOFF.
Topreventelectricshockdonotremoveany
coversoropentheelectricalenclosuredoor
whilethepowerisON.
8.Closealluidsupplyvalves.
9.SetPRESSURERELIEF/SPRAYvalvestoSPRAY
tosealoutmoisturefromthedrainline.
10.Engagegunpistonsafetylockthenclose
uidinletvalvesAandB.
