Repair
Replace Replace
Replace
Electric Electric
Electric
Motor Motor
Motor
Remove Remove
Remove
NOTICE NOTICE
NOTICE
Becarefulnottodropordamagethemotor.
Themotorisheavyandmayrequiretwo
peopletolift.
1.FollowShutdown,page50.
2.Openelectricalenclosure.Disconnectthe
AsideheaterconnectorfromtheTCM.See
ElectricalSchematics,page105.Closethe
electricalenclosuredoor.
3.Removemountingboltsfromthebottom
frameandmovethesystemawayfromthe
wall.
Figure2
4.Removeupperbolts(3).Tilttheelectrical
enclosuredowntogainaccesstothemotor
cover.
5.Removemotorandbeltcovers(123,131,
132).Liftcover(132)andloosentheblue
bracket(131)fasteners.Liftthebluebracket
(133)offofthefastenersandsetaside.
Removethebeltcovers(131,132).
Figure3MotorandBeltCovers
Figure4HeaterandBeltCovers
334946J
59
