Graco Reactor 2 H-XP3 Repair Parts

Repair
Pumpline Pumpline
Pumpline
Disassembly Disassembly
Disassembly
1.FollowthePressureReliefProcedure,page
49.
2.Removeplugtting(206)fromlubecylinder
(205).
3.Insertclevispinremovaltool296607
throughopeninginlubecylinder(205)and
screwtoolintoleftclevispin(219).Pull
clevispinoutofclevis(117).
4.Usehexkeytoremovefoursocketheadcap
screws(203)fromleftproportioningpump
(202).Removeleftproportioningpump.
5.Removelubecylinder(205).
6.Screwpinremovaltool296607intoright
clevispin(219).Pullclevispinoutofclevis
(117).
7.Usehexkeytoremovefoursocketheadcap
screws(203)onrightproportioningpump
(202).Removerightproportioningpump.
334946J
53
