Repair

Repair Repair

Repair

Proportioning Proportioning

Proportioning

Pumps Pumps

Pumps

1.FollowBeforeBeginningRepair,page52.

2.TurnbothPressureRelief/Sprayvalve(SA,

SB)toPressureRelif/Circulation.Routeuid

towastecontainersorsupplytanks.Ensure

gauges(GA,GB)dropto0psi.

NOTE: NOTE:

NOTE:

Usedropclothorragstoprotectthe

Reactorandsurroundingareafromspills.

3.DisconnecttheB(Resin)sidepumpinlet

line,theinlety-strainer,andhardtube(57).

Removethepin(213)fromtheclevis(317)

todisconnectthepumpfromthehydraulic

cylinder(201).Removethefourscrews(203)

holdingthepumptothespacers(313)of

thecylinder.Takethepumpassemblytoa

workbench.

Torque to 200 in. - lb (22.6 N•m).

4.DisconnecttheA(ISO)sidepumpinletline,

theinlety-strainer,andhardtube(55).

Usethepinextractortool(101)toremove

thepin(213),whichdisconnectsthepump

fromthehydrauliccylinder(201).Remove

thefourscrews(203)holdingthepumpto

thespacers(313)ofthecylinder.Takethe

pumpassemblytoaworkbench.

Torque to 200 in. - lb (22.6 N•m).

5.Seepumpmanualforrepairinstructions.

6.Reconnectthepumpinthereverseorder.

Torquethescrewsto200in.-lb(22.6N•m)

334946J
