Graco Reactor 2 H-XP3 Repair Parts

Repair
Replace Replace
Replace
Flow Flow
Flow
Meter Meter
Meter
NOTE: NOTE:
NOTE:
ForH-30,H-40,andH-50Elitemodels
only.
1.PerformShutdown,page50.
2.PerformPressureReliefProcedure,page49.
3.Disconnecttheowmetercable.
4.Disconnectthehose.Removetheow
meter.
5.Installthenewowmeterandreconnectthe
hose.
Figure6:FlowMeter
6.Connecttheowmetercable.
7.Enterthek-factoronSystemScreen3on
theADM.RefertoSystem System
System
3 3
3
inyourReactor
operationmanual.
Replace Replace
Replace
Pressure Pressure
Pressure
Transducers Transducers
Transducers
1.Flush.SeeFlushing,page51.
2.SeeShutdown,page50.
3.Disconnecttransducercables(405)from#6
and#7connectorsontheHCM.
4.Removewiretiesconstrainingtransducer
cableandremovecablefromcabinet.
5.Installo-ring(406)onnewtransducer(405).
6.Installtransducerinmanifold.Markend
ofcablewithtape(red=transducerA,
blue=transducerB).
7.Routenewcableintocabinetandthread
intobundleasbefore.Attachcabletiesto
bundleasbefore.
8.ConnectAsidepressuretransducercable
toHCMport#6.ConnectBsidepressure
transducercabletoHCMport#7.
62
334946J
