Graco Reactor 2 H-XP3 Repair Parts

Repair
Replace Replace
Replace
RTD RTD
RTD
1.PerformShutdown,page50.
2.Waitforheatertocool.
3.Removeheatercovers.
4.Cutcabletiesaroundthewovenwrapwith
theRTDcable(512).
5.DisconnectRTDcable(512)fromTCM(453).
6.Loosenferrulenut(N).RemoveRTD(512)
fromheaterhousing(501),thenremove
RTDhousing(H).Donotremovetheadapter
(206)unlessnecessary.Ifadaptermustbe
removed,ensurethatmixer(510)isoutof
thewaywhenreplacingtheadapter.
7.RemoveRTDcable(512)fromwovenwrap.
8.ReplaceRTDcable(512).
a.ApplyPTFEtapeandthreadsealant
tomalepipethreadsandtightenRTD
housing(H)intoadapter(506).
b.PushinRTD(512)sotipcontactsheater
element(508).
c.HoldingRTD(512)againstheater
element,tightenferrulenut(N)3/4turn
pastnger-tight.
9.Routewires(S)asbeforethroughwoven
wrapandreconnectRTDcable(512)tothe
TCM.
10.Replaceheatercovers.
11.Followstartupinstructionsintheoperation
manual.TurnonAandBheatsimultaneously
totest.Temperaturesshouldriseatsame
rate.Ifoneislow,loosenferrulenut(N)
andtightenRTDhousing(H)toensureRTD
tipcontactstheheaterelement(212)when
ferrulenut(N)isretightened.
Figure7
64
334946J
