Graco Reactor 2 H-XP3 Repair Parts

Repair
Update Update
Update
ADM ADM
ADM
Software Software
Software
1.TurnthemainpowerswitchOFF.
2.Openthetopandbottomdoorlatchestothe
electriccabinet.
3.Opentheelectricalcabinet.UseaPhillips
screwdrivertoloosenthefourADM
mountingscrewsontheinsideofthecabinet
door.
4.LifttheADMupandpullitawayfromthe
Reactortounseatthemountingscrews.For
easyreassembly,leavetheloosenedscrews
attachedtotheADM.
5.Removethetokenaccesspanelontheback
oftheADM.
6.Insertandpressthesoftwareupgradetoken
rmlyintotheslot.
NOTE: NOTE:
NOTE:
Thereisnopreferredorientationof
thetoken.
7.Closetheelectricalcabinet.
8.TurnthemainpowerswitchON.
NOTICE NOTICE
NOTICE
Astatusisshownwhilesoftwareis
updatingtoindicateprogress.Toprevent
corruptingthesoftwareload,donot
removethetokenuntilthestatusscreen
disappears.
NOTE: NOTE:
NOTE:
WhentheADMdisplayturnson,you
mayseethefollowingscreens:
First: First:
First:
Software is checking
which modules will
take the available
updates.
Second: Second:
Second:
Status of the
update with
approximate time
until completion.
Third: Third:
Third:
Updates are
compete. Icon
indicates update
success/failure. See
the following table.
Icon Icon
Icon
Description Description
Description
Updatesuccessful
Updateunsuccessful
Updatecomplete,nochanges
necessary
Moduleswereupdatedordid
notrequireanupdate;however,
oneormoremodulesneedtobe
updatedmanuallywithatoken.
9.Presstocontinuetotheoperation
screen.
10.TurnthemainpowerswitchOFF.
11.Removethesoftwareupdatetoken.
12.Replacethetokenaccesspanel.
13.Opentheelectricalcabinet,remountthe
ADM,andfullytightenthefourmounting
screws.
14.Closethelockandthecabinetdoorwiththe
doorlatches.
74
334946J
