Graco Reactor 2 H-XP3 Repair Parts

Repair
Replace Replace
Replace
Belt Belt
Belt
1.FollowShutdown,page50.
2.Removetheheatercover(134)andthebelt
coverfasteners(19).
NOTICE NOTICE
NOTICE
Topreventdamagetotheovertemperature
switch,carefullyremovethecovers.
3.Liftcover(132)andloosenthebluebracket
(131)fasteners.Liftthebluebracket(133)
offofthefastenersandsetaside.Remove
thebeltcovers(131,132).
4.Removethebelt.
5.Installthenewbeltandreplacethecovers.
Replace Replace
Replace
Fluid Fluid
Fluid
Inlet Inlet
Inlet
Sensor Sensor
Sensor
NOTE: NOTE:
NOTE:
ForElitemodelsonly.
1.PerformShutdown,page50.
2.PerformPressureReliefProcedure,page49.
3.Disconnectinletsensorcablefromthe
uidinletassembly.Inspectcablefor
damageandreplaceifnecessary.See
ElectricalSchematics,page105.
4.Toreplacesensorcable:
a.Cutanywiretiesand
disconnectfromHCM.See
ElectricalSchematics,page105.
NOTICE NOTICE
NOTICE
Topreventdamagetocable,securecable
withwireties.
5.Replacesensorandsecurewithwireties.
334946J
61
