Parts
Proportioner Proportioner
Proportioner
Assembly Assembly
Assembly
Parts Parts
Parts
1
Torqueto200in-lb(22.6N●m).
2
Pin(213)tobeclockedhorizontalasshown.
3.
Applysstpipesealanttoallnon-swiveling
pipethreads.
4
Removecoverfromdirectionalvalve(207)
andattachsolenoidharnesswires(225).See
ElectricalSchematics,page105.
5
Fullyseatpin(213)withahammerand
punch.
6
Threadinproximityswitch(211)alltheway
untilitcontactstheclockingplate,thenback
offa1/4–1/2turn.
7
Applygreasetoo-rings(204,216)before
assembly.
334946J
89
