Troubleshooting
Error Error
Error
Location Location
Location
Type Type
Type
Description Description
Description
Cause Cause
Cause
Solution Solution
Solution
BadRTDorbad
RTDplacement
againstheater
SwapAandBheater
outputcablesandRTD
cablesandseeifissue
follows.Ifso,replace
RTD.
Badheater
element
Conrmresistanceof
heater.Heaterresistance
shouldbe9-12Ωfor10
kWsystems,6-8Ωfor
15kWsystems,4–6Ωfor
20kWsystems.Ifoutof
tolerance,replaceheater
element.
Looseheater
wires
Checkforlooseheater
elementwires.
T8DB
HeaterB
NoTemperature
RiseB
Startedspraying
beforeheater
reached
operating
temperature
Waituntiloperating
temperaturehasbeen
reachedbeforespraying
orrecirculating.
T8DH
Hose
NoTemperature
RiseHose
Startedspraying
beforeheater
reached
operating
temperature
Waituntiloperating
temperaturehasbeen
reachedbeforespraying
orrecirculating.
V1IT
TCM
LowVoltageCANBad24VDC
powersupply
Checkvoltageofpower
supply.Voltageshould
be23-25VDC.Ifoutof
tolerance,replacepower
supply.
V2ITTCM
LowVoltageCANBad24VDC
powersupply
Checkvoltageofpower
supply.Voltageshould
be23-25VDC.Ifoutof
tolerance,replacepower
supply.
Looseconnection
ortrippedcircuit
breaker
Checkwiringforloose
connectionortripped
circuitbreaker.
V2MATCM
LowVoltageA
Lowincoming
linevoltage.
Measurevoltageatcircuit
breakerandensure
voltageisgreaterthan
195VAC.
Looseconnection
ortrippedcircuit
breaker
Checkwiringforloose
connectionortripped
circuitbreaker.
V2MBTCM
LowVoltageB
Lowincoming
linevoltage
Measurevoltageatcircuit
breakerandensure
voltageisgreaterthan
195VAC.
334946J
35
