First contact
L-SOLUTION 800 machine . 21
Electrical connections of the machine
Stand behind the machine (diagram 1).
1. Plug in the input/output machine-exhaust system connection cable , first to the exhaust
system, then to the LASER machine. Tighten the connectors screws using the screwdriver (3.5).
The connectors screws must be very tight to avoid accidental disconnection of the
cables while the machine is turned on as this could permanently damage the electronic
cards (label ).
Before making any user standard inputs/outputs connections you must check taht the
electric and electronic features of the different inputs and outputs are respected (see
"the Automaton function" described in the chapter "System operation" page 74).
A bad connection can irreparably damage the electronics of your machine.
2. Plug in the user standard inputs/outputs connection cable to the LASER machine if you use
the Automaton function described in the chapter "System operation" (see page 74).
The use of the function Automaton means that the engraving machine cannot be
considered individually to ensure the safety of the operator.
The engraving machine is actually integrated into a global process (the automated
production line).
Consequently, it is the final work station (engraving machine + automaton + loading
robot) that must comply with the regulations in terms of safety.
The person who fits the engraving machine within the manufacturing process is
therefore responsible for the EC compliance of the final work station.
3. Plug in the electric cable , first to the engraving table, then to the mains supply..
To cut off the mains supply to your machine in case of severe problems, unplug the
mains cable or switch off the machine with the main stop button at the front
of the LASER engraving machine (pict. 2). Make sure that you can reach them easily.
The electrical plug acts as a sectioning device. It is therefore important that you set
up the machine in order to always have easy access to the power cable.
Do not connect this equipment to an IT power supply card.
Installation
