First contact
Automaton function (user standard Inputs /Outputs)
Before making any user standard inputs/outputs connections you must check taht the
electric and electronic features of the different inputs and outputs are respected
(chart 1 and 2).
A bad connection can irreparably damage the electronics of your machine.
The use of the function Automaton means that the engraving machine cannot be
considered individually to ensure the safety of the operator.
The engraving machine is actually integrated into a global process (the automated
production line).
Consequently, it is the final work station (engraving machine + automaton + loading
robot) that must comply with the regulations in terms of safety.
The person who fits the engraving machine within the manufacturing process is
therefore responsible for the EC compliance of the final work station.
Access to the menu for activation of the Automaton function is through menu CONFIGURATION (see «CONFIGURATION
(SETUP) sub-menu» previous page). This function enables you to configure your engraving machine as an automaton in
a automised line (production line).
Once activated, the engraving machine will be controlled from signals sent by the automaton port.
In order to use this Automaton function, it is necessary to configure the Inputs / Outputs:
You can define four inputs (I1 to I4) from the 4 available (Start, Pause, Return to origin plate and Next file).
You can define four outputs (O1 to O4) from the 3 available (Exhaust system, Pause and Plate origin).
An available input or an available output can be chosen several times.
I1=0 I2=0 I3=0 I4=0
O1=0 O2=0 O3=0 O4=0
Available inputs Available outputs
0 . No wished input 0 . No wished output
1 . Start 1 . Exhaust system
2 . Pause 2 . Pause
3 . Return to origin (0,0) 3 . Origin (0,0)
4 . Next file 4 . - Not available -
Voltage and
current
Active state
Min. length of signal
(active state)
Input
Output
TTL compatible
Open collector
Low
200 m seconds
Number Name Direction Designation
1 O1 output output n°1
2 O2 output output n°2
3 O3 output output n°3
4 O4 output output n°4
5 5V 5V supply
6 I 1 input floating contact n°1
7 I 3 input floating contact n°3
8 0V ground
9 - not available
10 - not available
11 0V ground
12 0V ground
13 0V ground
14 I 2 input floating contact n°2
15 I 4 input floating contact n°4
Description of 15-point Sub_socket
Input and output signals characteristics
System operation
