3. Product Features
5
• The Display unit features a large LCD with EL backlighting.
• Three large easy to read data can be displayed in real time;
such as boost pressure, rpm, etc.
• Air/fuel ratio, throttle position and vehicle speed may be
displayed with the use of an optional Signal harness
(sold separately).
• The GReddy Warning gauge data can be displayed with the
use of an optional data link cable (sold separately).
• Built-in Warning feature for all input signals; such as boost,
rpm, etc.
• Link up to e-Manage to tune and save using Standard A/B
USB cable (available through any computer supply retailer).
• Able to record up to 3 hours of data and play back on the
display.
• Controls boost up to 3kg/cm (Depending on the turbo system).
Select from Auto and Manual boost mode to boost up to a
desired pressure.
• Boost pressure may be adjusted at different rpm points to
achieve consistent boost levels.
• Uses compact high volume solenoid valve.
• Uses high quality pressure sensor.
• Able to lower the boost pressure when the warring feature is
activated.
• Boost pressure may instantly be increased by using the Over
Take Boost feature. This feature can be used with the
Optional Remote Switching System (sold separately).
Important!
Standard A/B USB cable is required in order to link the e-01 to
the e-Manage unit. This is available at any computer supply
retailer.
Pressure sensor
Engine
Turbo
Valve unit
Air cleaner
Actuator
Fuel regulator
Intercooler
Center unit
Controller
Display unit
2
