GMV5 Home DC Inverter Multi VRF Units
319
6. Fix and wire the
electric box.
●Put the electric box back to
original position and screw it up.
●Connect all wires.
7. Check and install
the front panels.
●Check the parts and connecting
wires;
●If no problem is found, hook the
front panels and tighten the
screws.
Assembly and disassembly of oil separator
Precondition: No refrigerant exists in the pipeline system and the power supply has been disconnected.
1. Loosen the hooks
at the bottom of the
electric box and the
screws.
●Remove the left and right front
panels and set them aside;
●Loosen the hooks at the bottom
of the electric box.
● Use a screwdriver to unscrew
the electric box.
2. Remove the
electric box.
●Disconnect internal and external
connecting wires of the electric
box.
●Protect the internal parts during
the disassembly.
To Next Page
