GMV5 Home DC Inverter Multi VRF Units
340
3.4.2 Board Connection Wire
There are 2 board connection wires supplied for the commissioning tool kits. One is 1
meter long and the other is 5.5 meters long. They are only different in length. One end of
the wire shall connect with air conditioner communication interface and the other end
shall connect with Gree USB converter CAN interface. As shown below, the wire can be
connected to the communication interface of outdoor unit or the communication interface
of indoor unit:
4 Software Introduction
4.1 Installation Requirements
4.1.1 Computer Configuration
1 GB at least
2 GB or larger is preferred
