Model 672/675 Technical Reference Manual
2-9
4. Line up the holes of the multi-scale option module with the holes located on the right side of the notch on
the option-mounting bracket.
5. Install the (4) aluminum standoffs in the holes with the (4) screws on the underside of the bracket
(labeled ETH). Refer to Figure 2-4 for configuration.
6. Position the multi-scale option module on the standoffs so the ribbon cable points away from the notch
on the option-mounting bracket. Install the (4) hex nuts to secure the option board.
7. If more than one SBM module is being used, connect the 6" option ribbon cable from J1 to J2 of the next
option.
8. The last option in the chain will use a 22-30-35454 10" ribbon cable (optional) to connect the option
module to the main board.
9. Reinstall the enclosure bottom plate.
S
ETUP
P
ARAMETERS
Multi-scale setup parameters beginning at P108 → P142 are used to setup the multi-scale option module.
Each scale is selected as an instance, 1 → 4 on the Model 675 and 1 → 2 on the Model 672. Refer to page
3-39 for complete configuration details.
A/D C
ALIBRATION
A printout of the A/D calibration information accompanies each multi-scale option module on a sheet inside
the anti-static bag with the circuit board. These parameters must be entered into the Module 672/675 in
order for it to read the scale input accurately. A sample printout appears below:
100%s23640%i%e
61099%s2%e P61099. Scale 2
61101%s 1.000000%e P61101. CAL Factr 1.000000
61102%s 0.000000%e P61102. ReZro Wght 0.000000
61103%s 0.000000%e P61103. ZrTrk Wght 0.000000
61104%s8%e P61104. CZero 0%%
61105%s 60573%e P61105. Fine Zero 60573
61106%s2%e P61106. CGain 100
61107%s 1.250029%e P61107. Fine Gain 1.250029
61110%s 64409%e P61110. Zero Adj25 64409
61111%s -26859%e P61111. Zero Adj50 -26859
61112%s -198972%e P61112. Zero Ad100 -198972
61113%s 0.942661%e P61113. Gain Adj1 0.942661
61114%s 0.945947%e P61114. Gain Adj2 0.945947
61115%s 0.955080%e P61115. Gain Adj4 0.955080
61116%s 0.956094%e P61116. Gain Adj8 0.956094
61117%s 808%e P61117. AIN NROff 808
61118%s -1519%e P61118. AIN NROff -1519
61119%s -1995%e P61119. AIN NROff -1995
61120%s -4857%e P61120. AIN NROff -4857
61121%s -1070%e P61121. VREF NROff -1070
61122%s 111111%e P61122. SN: 111111
64102%s View errors after uploading!
Operator: rg
Date:mmddyy=090604
420919-36553 Multi-scale Option Board
ATR-31565
The values indicated in bold define the A/D calibration values for the multi-scale option module. They must
be keyed into and stored in their respective parameters for accurate operation. The serial number (P61122)
is intended to allow you to associate these setup parameters to a specific multi-scale option module. Contact
GSE with the part number and serial number of the multi-scale board if the calibration sheet is misplaced.
Refer to page 5-8 for complete details on A/D calibration.
