Application Setup
Chapter 3
3-18
Style 3
This style incorporates the classic GSE 2x5 display along with three smaller displays which will show four
other parameters. Press the [SELECT] key from the APW LOOKUP screen to toggle through the different
parameter choices.
Set Modes
After choosing a display style there are several modes of operation (such as Gross and Quantity) to choose
from. These modes are accessible by using the [SELECT] key while viewing the APW LOOKUP mode. The
ability exists to enable or disable each choice.
1. Press [F4] to access the SET MODES menu.
2. Use the [F1] Next Mode key to toggle through the available modes.
3. Use the [F2] Enable Mode key to enable the mode.
4. Use the [F3] Disable Mode key to disable the mode.
5. Press [F5] to exit back into the APW LOOKUP screen.
Print Menu
PARAMETER DESCRIPTION
DEFAULT
SETTING
KEYPRESSES
PRINT PART#S
Print stored part numbers to printer
or computer
Not applicable
Print data to comm. 1, 2 or display. Use [F1] or
[F2]
D-LOAD PART#S
Download part number, description,
average piece weight and tare weight
in comma delimited format
Not applicable Print data to comm. 1or 2. Use [F1] or [F2]
PRINT FORMATS Choose what information to print out Print Style 1
Use [F3] and [F4] to view print format choices.
Press [F5] to save the format
Preset Print Formats
The preset print formats are viewable on the LCD display. Use the [F3] left arrow and [F4] right arrow keys
to view all transmit styles. Chose the desired format by viewing it on the screen. Press the [F5] (EXIT) key to
save the format and return to the main menu.
Large Display Small Display Small Display Small display
Quantity Gross Net Tare
Quantity Part# Piece Weight Tare
Quantity Net Tare Gross Total
Gross Part# % Accuracy Piece Weight
Quantity Part# % Accuracy APW x 100
Quantity Piece Weight % Accuracy Tare
