GSE 672 - FRAM Database; Analog Output Option (Model 675 Only)

Model 672/675 Technical Reference Manual
2-37
9990%s2%e P9990.XX Macro #2
P19999.2%s%c%e P19999.2 macro table
3%%g%e 0001 if sample error
4%%g%e 0003 if sample error
5%%g%e 0005 if sample error
%%B%e 0007 break
%%E%e 0008 end if
6%%g%e 0009 if sample error
ABORTSMPLE%%S%e 0011 sound beeper
%%P%e 0022 pause
%%B%e 0023 break
%%E%e 0024 end if
%z%e Exit Setup Mode
FRAM D ATABASE
You can allocate a portion of the resident FRAM for general database usage. This provides all the
functionality of the 256K database option, but in a 4K, 8K or 12K capacity.
To configure the FRAM database:
1. From the weigh mode, key in 698 [SELECT] 23640 [ENTER]
2. Press [ENTER] to toggle through the choices.
3. When the desired choice is displayed, save the changes and exit the setup mode by pressing [ZERO]
[CLR] [ENTER] [ENTER].

If only one FRAM is installed, the choice for 8K will display FRMdb 8Kopt, No 2ndFRAM. An
additional 8K FRAM must be installed in the U28 socket.
If a optional database is detected at power-up, the internal FRAM database will be ignored and the external
option will take precedence. This will not eliminate the structure or data of the FRAM database. It will
remain hidden and intact until the external database option is remove or until a default (P65001-65002),
database reset (P65010) or [CLR] at P698 is performed. Presence of an external database will not allow
P698 to be enabled.
Defaulting at P65001 or P65002 clears P698 to "None!". Pressing the [CLR] key at P698 will do the same.
These are the only ways to disable the FRAM database and free up FRAM memory if an external database
option is also installed. The FRAM database will be retained if you do not save changes when exiting setup
after a default. This is also true for a database reset (P65010).
The amount of FRAM installed can be viewed at P60000. Press the [ENTER] key to view the amount of
FRAM installed. Information parameters 60010-60012 show additional information regarding database
memory allocation (see page 10-5).
INSTALLING ADDITIONAL FRAM
Up to an additional 32K of FRAM may be installed for extra database storage or setup storage. Install the
FRAM into the socket at U19 on the Model 672 and U28 on the Model 675. Be sure to observe polarity of
the socket and FRAM chip.
A
A
N
N
A
A
L
L
O
O
G
G
O
O
U
U
T
T
P
P
U
U
T
T
O
O
P
P
T
T
I
I
O
O
N
N
(
(
M
M
O
O
D
D
E
E
L
L
6
6
7
7
5
5
O
O
N
N
L
L
Y
Y
)
)
This section provides procedures for installing the analog output module.
The analog output modules enable the Model 675 to generate a 0-10VDC, active 0-20mA or active 4-20mA
output signal corresponding to the value of most operating parameters.
