Option Installation
Chapter 2
2-38
Table 2-8: Analog Output Option Accessories
Quantity Part Number Description
4 17-20-3019 Standoff
4 38-21-0101 5x6mm screw
4 38-21-1640 Lock nut
1 420931-37216 Analog output board
1 26-50-7403P 3 position terminal
A single jumper on the analog output PC board (E1) selects whether it will be addressed as analog output 1,
2, 3, 4. Please note that the Model 675 has only four analog outputs available even through there are 8
positions on E1.
I
NSTALLATION
N
OTES
Make sure E1 is configured for the correct analog output number selection.
If another module is in use, such as another analog or multi-scale module, connect it to J2 (NEXT) on
the previous module.
If any I/O modules are to be installed, they must be daisy chained after all multi-scale and analog
output modules.
Route any cables through a strain relief making sure to connect any shield wires to a ground stud.
Installation Instructions
1. DISCONNECT POWER! UNPLUG THE MODEL 675 TO INSURE DAMAGE WILL NOT OCCUR
DURING OPTION INSTALLATION
2. Remove the (6) 38-31-8710 M5 x 0.8 x 10 mm screws from the enclosure bottom plate and set it aside.
3. Find the side of the option mounting bracket that is labeled with OPT. You will find this label in two spots
on this side.
4. Line up the holes of the analog output option board with the holes located on the right side of the notch
on the option-mounting bracket.
5. Install the (4) aluminum standoffs in the holes with the (4) screws on the underside of the bracket
(labeled ETH).
6. Position the Analog Output Option Board on the standoffs so the ribbon cable points towards the notch
on the option-mounting bracket. Install the (4) hex nuts to secure the option board.
7. If more than one SBM module is being used, connect the 6" option ribbon cable from J1 to J2 of the next
option.
8. The last option in the chain will use a 22-30-35454 10" ribbon cable (optional) to connect the option
board to the main board.
9. Install the option-mounting bracket in the Model 675 enclosure. Refer to page 2-6 for option mounting
bracket installation instructions. Refer to Figure 2-14 for a reference to installed options.
10. Connect all necessary wiring to the Analog Output Option Board.
11. Reinstall the enclosure bottom plate.
A
NALOG
O
UTPUT
P
ARAMETER
S
ETUP
Analog output setup parameters beginning at P170 → P177 are used to setup the output module. Each
output is selected as an instance, 1 → 4. Refer to page 3-41 for complete configuration details.
