GSE 672 - Reflash Software

Option Installation
Chapter 2
2-46
BHT-23 v1.00P4,5%%C%e display text
%%P%%P%%P%e pause (3 seconds)
%z%c%e%e Exit Setup Mode
Example #6: Setpoint Timer
100%s23640%i%e Access Setup Modes
5099%s4%e SPT #4
5100%s1%e SPTyp Outpt
5101%s%c SPNam TIMER
5110%s5%e Activ Never
5111%s0.00%e AcDly 0.00
5112%s0%e AcMac None!
5113%s0%e AcMtn Ign'd
5130%s4%e Deact Alwys
5131%s15.00%e DeDly 15.00
5132%s15%e DeMac 15
9990%s4%e%e MACRO #4
9991%s%c ACTIVATE TIMER
19999.4%s%c%e
4%%A%e activate timer
9990%s15%e%e MACRO #15
9991%s%c TIMER ACTIVATED MACRO
19999.1%s%c%e
MIX TIMER EXPIREDP5,4,f2%%C%e display text
%%P%%P%%P%e 3 second pause
Pa%%C%e clear display
R
R
E
E
F
F
L
L
A
A
S
S
H
H
S
S
O
O
F
F
T
T
W
W
A
A
R
R
E
E
The Reflash software is a utility which allows the Model 672/675 to be flashed through a comm port. The
firmware is loaded into a flash memory IC. This allows for ease in loading firmware updates. The part
number is 24660B-403B0.
