Model 672/675 Technical Reference Manual
2-45
5110%s2%e P5110.2 Activ Betwn
5112%s0%e P5112.X AcMac none
5113%s1%e P5113.1 AcMtn Inhib
5114%s80.1%e P5114. ALPar VAR#1*
5115%s80.2%e P5115. AUPar VAR#2*
5130%s3%e P5130.3 DeAct Outsd
5132%s0%e P5132.X DeMac none
5133%s1%e P5133.1 DeMtn Inhib
5134%s80.1%e P5134. DLPar VAR#1*
5135%s80.2%e P5135. DUPar VAR#2*
5150%s0%e P5150.0 CmPar Gross
*(set VAR#1 to 0.5 and VAR#2 to 10)
SET 2ND SMALLEST GRADE RANGE
5099%s2%e P5099.2 Setpt 2
5100%s1%e P5100.1 SPTyp Outpt
5110%s2%e P5110.2 Activ Betwn
5112%s0%e P5112.X AcMac none
5113%s1%e P5113.1 AcMtn Inhib
5114%s80.3%e P5114. ALPar VAR#3*
5115%s80.4%e P5115. AUPar VAR#4*
5130%s3%e P5130.3 DeAct Outsd
5132%s0%e P5132.X DeMac none
5133%s1%e P5133.1 DeMtn Inhib
5134%s80.3%e P5134. DLPar VAR#3*
5135%s80.4%e P5135. DUPar VAR#4*
5150%s0%e P5150.0 CmPar Gross
*(set VAR#3 to 10 and VAR#4 to 20)
SET THIRD SMALLEST GRADE RANGE
5099%s3%e P5099.3 Setpt 3
5100%s1%e P5100.1 SPTyp Outpt
5110%s2%e P5110.2 Activ Betwn
5112%s0%e P5112.X AcMac none
5113%s1%e P5113.1 AcMtn Inhib
5114%s80.5%e P5114. ALPar VAR#5*
5115%s80.6%e P5115. AUPar VAR#6*
5130%s3%e P5130.3 DeAct Outsd
5132%s0%e P5132.X DeMac none
5133%s1%e P5133.1 DeMtn Inhib
5134%s80.5%e P5134. DLPar VAR#5*
5135%s80.6%e P5135. DUPar VAR#6*
5150%s0%e P5150.0 CmPar Gross
*(set VAR#5 to 20 and VAR#6 to 30)
%z%c%e%e Exit Setup Mode
Example #5: Power Up Setpoint
100%s23640%i%e Access Setup Modes
5099%s250%e SPT #250
5100%s1%e SPTyp Outpt
5101%s%c SPNam POWER-UP
5110%s4%e Activ Alwys
5111%s0.00%e AcDly 0.00
5112%s250%e AcMac 250
5113%s0%e AcMtn Ign'd
5130%s5%e Deact Never
5131%s0.00%e DeDly 0.00
5132%s0%e DeMac None!
9990%s250%e%e MACRO #250
9991%s%c POWER-UP
9994%s1%e limited access enabled
19999.250%s%c%e
@POWER-UP%%T%e tag POWER-UP
1%%Q%e send DISPLAY TEST
%%P%%P%e pause
CUSTOMER NAME INC.P1,2a%%C%e display text
Packaging SystemP3,3%%C%e display text
