Option Installation
Chapter 2
2-44
(set VAR2 to 25)
5130%s1%e P5130.1 DeAct Below
5131%s0%e P5131.1 DeDly 0.00
5132%s0%e P5132.X DeMac none
5133%s0%e P5133.0 DeMtn Ign'd
5134%s80.2%e P5134.1 DLPar VAR#2
5150%s0%e P5150.0 CmPar Gross
%z Exit Setup Mode
Example #2: Latching Relays
100%s23640%i%e Access Setup Mode
NAME VAR#1 FOR SETPOINT 1 TARGET VALUE
682%sSP-1 VALUE%e P682.-- Var#1 SP-1 VALUE
SET SP-1 ACTIVATION POINT TO 100% OF VAR#1 VALUE
5099%s1%e P5099 Setpt 1
5100%s1%e P5100.1 SPTyp Outpt
5110%s0%e P5110.0 Activ Above
5111%s0%e P5111.1 AcDly 0.00
5112%s1%e P5112.X AcMac 1*
5113%s0%e P5113.0 AcMtn Ign'd
5114%s80.1%e P5114.1 ALPar VAR#1
*Set macro 1 up to multiply the value of VAR1 by 95% and place the result in VAR2.
SET SP-1 DE-ACTIVATION POINT TO 95% OF VAR#1 VALUE
5130%s1%e P5130.1 DeAct Below
5131%s0%e P5131.1 DeDly 0.00
5132%s0%e P5132.X DeMac none
5133%s0%e P5133.0 DeMtn Ign'd
5134%s80.2%e P5134.X DLPar VAR#2
5150%s0%e P5150.0 CmPar Gross
%z%c%e%e Exit Setup Mode
Example #3: Activate on [TARE]
100%s23640%i%e Access Setup Modes
NAME VAR#1 FOR SETPOINT 1 TARGET VALUE
682%sSP1 TARGET%e P682.-- Var#1 SP1 TARGET
SET TARE KEY TO ACTIVATE MACRO #1
802%s1%e set to invoke macro 1
SETUP SETPOINT TO DEACTIVATE AT TARGET (100% OF VAR#1 VALUE)
5099%s1%e P5099.1 Setpt 1
5100%s1%e P5100.1 SPTyp Outpt
5110%s6%e P5110.4 Activ Never
5130%s0%e P5130.0 Deact Above
5131%s0%e P5131.1 DeDly 0.00
5132%s16%e P5132.X DeMac none
5133%s0%e P5133.0 DeMtn Ign'd
5134%s80.1%e P5134.1 DLPar VAR#1
5150%s1%e P5150.1 CmPar Net
9990%s1%e macro 1.
10000%s%c%e
%%t%e tare.
1%%A%e activate setpoint 1.
%z%c%e%e Exit Setup Mode
Example #4: Grading (Up to 32 Ranges)
100%s23640%i%e Access Setup Modes
SET SMALLEST GRADE RANGE
5099%s1%e P5099.1 Setpt 1
5100%s1%e P5100.1 SPTyp Outpt
