Application Setup
Chapter 3
3-22
VIEW ONLY ACCESS
It is possible to view the current configuration of the model 672 or Model 675 by simply keying in the desired
parameter number. This is only for viewing current parameter values, no modifications will be allowed.
For Example,
200 [ENTER]
The display will show “No Mods!” before accessing the parameter. This indicates that no modifications can
be made to any parameter. Changing parameter selections are only possible by entering the setup mode
using the full-edit access method.
FULL EDIT ACCESS
In order to change the current selection for any of the setup parameters you must access the setup mode by
keying in the desired parameter number and entering a security access code. The default GSE access code
is 23640. For example,
100 [SELECT] 23640 [ENTER]
This will display the first setup mode parameter and allow changes to all parameter selections.
Accessing a Specific Parameter
You can access a specific parameter by keying in the parameter number (and applicable instance) prior to
pressing [SELECT]. For example,
5100.2 [SELECT] 23640 [ENTER]
This will proceed directly to parameter 5100 for setpoint #2 upon entering the setup mode. This method also
works with view-only and limited access.
LIMITED ACCESS
Whereas the full-edit access method allows changes to all setup parameter selections, using the limited
access code permits changes to be made to all parameters except any macros or custom transmits that are
protected by limited access.
The default GSE limited access code is 21353 [ENTER].
100 [SELECT] 21353 [ENTER]
This will access the setup mode using limited access. Any macros or custom transmit tables that are
protected by limited access at P9994 or P999 respectively will not be viewable, cannot be changed and will
not appear in the download output at P64000. This allows the programmer to give others access to
important field configurable parameters such as zero tracking and motion delay while protecting the main
program routines from unauthorized changing or copying. When using the limited access code it is
advisable to assign a PIN number to the full-edit access code at P400 as the default GSE access code is
widely known and if used will give full access to all setup parameters.
Parameter Description
P10001 - 19999 Macros will not be viewable if specified as limited
access at P9994.
P400 - 402 PIN#s will not be viewable.
P1000 - 4999 Custom transmits will not be viewable or printable if
specified as limited access at parameter P999.
P50001 Macro debug will not be viewable if specified as
limited access at P50000.
P64000 - 64001 Sending setup will not print any parameter protected
by limited access.
