Application Setup
Chapter 3
3-24
ACCESSING A SPECIFIC PARAMETER
Key in a parameter number and press [SELECT] to access that parameter directly. For example,
[3] [0] [0] [SELECT]
will take you directly to P300 from any other parameter.
Multiple Instance Parameters
A multiple instance parameter can be directly accessed by including the desired instance number with the
parameter number. Separate the parameter number and instance with a decimal. For example,
[2] [0] [0] [ . ] [2] [SELECT]
will proceed directly to P200 (baud rate) for communication port 2.
OTHER NAVIGATING TOOLS
There are several short cut and special function keys used to aid in navigating the setup mode. The function
of these keys depends on the currently selected setup parameter (see Table 3-1). For a complete list of key
functions, see page 1-7.
Table 3-1: Setup Mode Key Functions
672/675 KEY DESCRIPTION
Advances to the next parameter or directly to a keyed-in parameter.
Moves back one parameter.
Scrolls through a list of choices or enters a keyed-in value.
Clears a keyed-in value or an entry in process.
Advances to the next instance of the currently displayed setup parameter.
Moves back to the previous instance of the currently displayed setup parameter.
#
Moves directly to the instance specified by '#' for the currently displayed setup parameter (for example
).
Shows the instance of the currently displayed multi-instance setup parameter. Only when the Alpha key is set for
ID Key at P806.
or
Begins alpha entries. Scrolls forward through alpha characters. Scrolls through the list of operating parameters in
the "Pick Parm" list.
Scrolls backward through alpha characters. Toggles between the normal and expanded view modes in a custom
transmit table.
Advances one character in the custom transmit, input interpreter and macro tables. Shifts right during alpha entry
to begin scrolling next character.
Moves back one character in the custom transmit, input interpreter and macro tables. Shifts left (backspace) one
character during alpha entry.
Exit setup mode or enter calibration.
+
Default database on power up.
