Application Setup
Chapter 3
3-26
setpoint comparison parameters (P5150).
To change an operating parameter, key in the desired parameter number and instance (if required) and
press [ENTER]. For example, selecting P5150 and keying in
[1][ . ] [3] [ENTER]
will enter the net weight of scale 2 as the setpoint compare parameter. If you forget to enter a required
instance, the display will prompt you to enter one.
If you do not know the number of the parameter you wish to specify, you can press [ENTER] to display the
Pick Parm: list. The list starts with the "Gross" parameter. Pressing the up/down arrow keys will scroll
forwards and backwards through all parameters. Press [ENTER] again to choose the displayed parameter
and enter the instance if prompted.
Clearing an Operating Parameter
If you wish to clear an operating parameter rather than enter a new one, key in 99 [ENTER] as the operating
parameter selection. The display will show “None!” as the operating parameter name. Note that some
setup parameters such as the setpoint compare parameter (P5150) require you to specify an operating
parameter before allowing you to exit the setup mode. If you have not entered a required operating
parameter before exiting, the display will revert to the offending parameter and allow you to enter one.
Viewing an Operating Parameter's Number & Instance
When viewing an operating parameter entry, all you see is the parameter name. You can toggle the display
to show the parameter's number and instance by pressing [F2].
E
XITING
T
HE
P
ARAMETER
S
ETUP
M
ODE
You can exit the setup mode from any parameter by pressing [ZERO] to initiate the exit routine. When
exiting you are given the opportunity to calibrate and save or undo all changes you made while in the setup
mode.
E
XIT AND SAVE CHANGES
The most common procedure for exit the setup mode is pressing [ENTER] to exit and save all changes
without calibrating the scale. With each keystroke you are prompted through the exit sequence.
EXIT AND UNDO CHANGES
You can exit the setup mode without saving any parameter changes by pressing [CLR] at the
“ENTER=SAVE” prompt. The display will then show
at which point you can press [ENTER] to undo all changes and [ENTER] again at the “ENTER=EXIT”
prompt to exit without saving.
SETUP
ENTER
=UNDO
