Spare Parts and Tools
Service Manual for Accutherm Ultra Printer C-xv
26 RETAINER-E RING .156 DIA. 10-2148-01E
27 ROLLER - SLACKER (Part # 28-09948) 16-2070-01E
28 ROLLER - EPIC 950 TRANSPOR
T (Part # 95-04907) 16-2071-01E
29 SCREW - #4 PLASTIC THREAD FORMING 10-2150-01E
30 SCREW - M 3 X 6 MM SEMS PHD PHPS
(Part # 98-02215)
10-2153-01E
31 SHAFT - TENSIONER (Part # 28-09691) 12-1024-01E
32 SHAFT - SLACKER (Part # 28-09692) 12-1025-01E
33 SHIELD -PCB (Part # 28-09833) 11-4270-01E
34 SPRING - PRINT HEAD COMPRESSION
(Part # 28-03765)
17-0946-01
35 SPRING - VALIDATION COMPENSATION LEFT
(Part # 25-07772)
17-1142-01E
36 SPRING - VALIDATION COMPENSATION, R
(Part # 25-07773)
17-1142-01E
Table C-9. Assembly-Lower Mechanism
Number Description
GTECH Part
Number
To Next Page
