GW Instek ASR-2000 Series User Manual

APPENDIX
213
Others
Protections
OCP, OTP, OPP, FAN Fail
Display
TFT-LCD, 4.3 inch
Memory Function
Store and recall settings, Basic settings: 10
Arbitrary
Wave
16 (nonvolatile)
4096 words
A value with the accuracy is the guaranteed value of the specification. However,
an accuracy noted as reference value shows the supplemental data for
reference when the product is used, and is not under the guarantee. A
value without the accuracy is the nominal value or representative value
(shown as type).
External Signal Input (AC+DC-EXT, AC-EXT Mode)
Specification
Factory Default
Gain setting range
100 V range: 0.0 to 250.0 times
100
200 V range: 0.0 to 500.0 times
200
Input terminal
BNC connector
Input impedance
1 MΩ
Input voltage range
±2.5 V (A/D resolution 12 bit)
Nondestructive maximum
input voltage
±10 V
Gain resolution
0.1 times
Accuracy
±5 %
(DC, or 45Hz ~ 65 Hz, gain is at initial value, with
rate voltage output, no load)
EXT: Output voltage (V) = External signal input (V) x Gain (V/V)
