GW Instek ASR-2000 Series User Manual

OPERATION
65
2. Choose an output mode with scroll wheel.
Mode
Description
AC+DC-INT
AC & DC Internal Output
AC-INT
AC Internal Output
DC-INT
DC Internal Output
AC+DC-EXT
AC & DC External Output
AC-EXT
AC External Output
AC+DC-ADD
AC & DC Additional Output
AC-ADD
AC Additional Output
AC+DC-Sync
AC & DC Synchronal Output
AC-Sync
AC Synchronal Output
AC-VCA
AC Voltage Control Amplifier
Output
INT
The signal source is from
internal. Set the output voltage,
waveform, frequency, on phase
and off phase through the control
panel or the remote control.
EXT
The signal source is from
external. Amplifies and outputs
the external input signal. Set the
voltage gain through the control
panel or the remote control.
ADD
The signals are the total of the
external and internal signal
source. Set the voltage gain for
the external input signal, the
output voltage for the internal
signal source, the output
waveform, frequency, on phase
and off phase through the control
panel or the remote control.
