H3C S3600 Series Ethernet Switches Chapter 1 Product Overview
1-11
LED Mark Status Indication
POST
running
The PWR
LED flashes
green
Displays the POST test ID (in the
range of 1 to 9).
The PWR
LED flashes
yellow
POST
failed
The PWR
LED is solid
red
Flashes the POST test ID of the
failed test.
Softwar
e
loading
The PWR
LED flashes
green
A bar rotates clockwise around the
LED.
Fan
failure
The PWR
LED is solid
red
Displays “F”.
7-segme
nt digital
LED
Unit
Unit ID
Button
released
Displays the unit ID in the fabric,
and displays “1” if there is only one
unit.
III. Attributes of the 10Base-T/100Base-TX Ethernet ports
The S3600-28TP-SI provides twenty-four 10Base-T/100Base-TX Ethernet ports
(numbered from 1 to 24) on the front panel. For attributes of these ports, see
Table 1-3.
IV. Attributes of the 1000Base-X SFP ports
The S3600-28TP-SI provides two 1000Base-X SFP ports numbered 25 and 26 on the
front panel.
SFP modules allow for great flexibility because they are hot swappable and user
configurable.
Table 1-5 lists the available SFP modules.
 Note:
z The types of 1000Base-X SFP modules may be subject to changes without notice.
Consult H3C marketing personnel or technical support personnel to obtain the latest
information about SFP modules.
z For specifications of SFP modules, refer to H3C Low End Series Ethernet Switches
Pluggable Modules Manual.
